Description

LEX  Syringe Filters are extremely suitable for HPLC/GC analytical sample preparation and remove the particulate from liquids and gasses. Both of Non-Sterile and Sterilization filters are available for a range of laboratory demands.

Instruction

How to choose the correct syringe filter for an application?

• Housing and Technology
• Diam and Pore Size
• Filter Media Application
• SterilizationApplication
• Filter Area and Operation Pressure
• Hold-up Volume

Housing and technology

Diam and pore size

Syringe filters with different pore size ratings are suitable for different applications. For example, for column systems using 3μm or larger size, a 0.45μm syringe filter is available. 0.2μm filter can be used for microbial filtration,(buffers, culture media). For turbid solutions can choose 1-5μm for pre-filtration and clarification.

Diam:4(mm),13(mm),25(mm),33(mm).

Filter media application

Application	Filter Media	Others Media
HPLC/UHPLC/LC/MS/GC	Nylon / PES(Polyethersulfone)	Hydrophilic PTFE
Gases,Acids/ Bases	Hydrophobic PTFE	/
Undiluted organic solution	Hydrophilic PTFE / Regenerated Cellulose	Nylon
ICP-MS	Hydrophilic PTFE	Glass Fiber+PTFE
Large particles of organic solution	Glass Fiber+PTFE	/
Tissue/Cell medium filtration	PES(Polyethersulfone)	CA(CELLULOSE ACETATE)
Protein analysis Biological sample buffer washing	Hydrophilic PVDF	Regenerated Cellulose
Large particles of the aqueous solution	Glass Fiber+Nylon	/

Sterilization application

• Filtration of aqueous and organic solutions.
• Filtration of cell and tissue culture media.
• Filtration of viral suspensions.
• Clarification of biological, protein, enzyme, probe, and hybridization buffers and other aqueous samples.

How to choose media?

Media	Housing Diameter(mm)	Pore Size(μm)	Application
PES(Polyethersulfone)	13，25，30	0.22，0.45	Buffer solutions Aqueous samples Biological samples Tissue culture media solutions, low protein binding
Nylon	13，25，30	0.22，0.45	Aqueous or organic samples Alcohols and weak solvents filtration HPLC solvents, alcohols, aromatic, hydrocarbons
Hydrophobic PTFE (polytetrafluoroethylene)	13，25，30	0.22，0.45	Organic solvent filtration Highly corrosive sample Air and gas venting filtration
Hydrophilic PTFE (polytetrafluoroethylene)	13，25，30	0.22，0.45	Organic and aqueous solutions Purification of aqueous and organic solutions Strongly corrosive or oxidizing filtration
Hydrophobic PVDF (polyvinylidene fluoride)	13，25，30	0.22，0.45	Air and gas venting filtration Aqueous or mild organic solutions
Hydrophilic PVDF (polyvinylidene fluoride)	13，25，30	0.22，0.45	Aqueous or mild organic solutions Biological solutions Serum and culture medium filtration Low protein binding
MCE(Mixed Cellulose Ester )	13，25，30	0.22，0.45	Aqueous samples General-purpose filtration Clarification and particulate removal
CA (CELLULOSE ACETATE)	13，25，30	0.22，0.45	Buffer solutions Aqueous samples Biological samples Serum and culture medium filtration
GF(Glass Fiber Filter)	13，25，30	0.22，0.45	Pre-filter Large particles filtration Organic solvents and strong acids Purification
PP(Polypropylene)	13，25，30	0.22，0.45	Pre-filter Organic and aqueous solutions Large particles filtration
RC(Recycled cellulose)	13，25，30	0.22，0.45	Corrosive sample filtration Organic and aqueous solutions for filtration and purification Low adsorption, low precipitation, low protein binding

Notice: Other sizes could available. 0.1~5.0μm
