Introduction

LEXFILTERS PES(Polyethersulfone) Pleated Cartridge Filter is the imported asymmetric polyethersulfone film is made by hot melt welding with high-temperature resistant polypropylene shell or stainless steel lining skeleton. Asymmetric structure aperture, high voltage, large circulation, are often used for liquid terminal sterilization filtration.

Application

• The beverage industry in all kinds of wine, mineral water, pure water, juice, and other liquid filtration.
• Terminal filtration of water for ultra-clean water preparation, optical disc, display screen, and polysilicon production in the electronics industry.
• The chemical industry in the filtration of high purity chemical products, ketone, fat, high molecular weight alcohol, and alkaline liquid filtration.
• Terminal filtration of bulk medicine, medicinal solvent, injection liquid, needle liquid, infusion liquid, distilled water, and other liquids in the pharmaceutical industry.

Product Features

• Low protein binding and wide chemical compatibility.
• Extremely high low rate and low-pressure drop.
• Resistance to hydrolysis allows use in Ultra Pure Water(UPW)system.
• Better replace for Sartorius;PALL;Millipore etc.

Technical Specification

Structural components

Media Material	PES(Polyethersulfone)
Inner Corn	Reinforced Polypropylene
Housing/Center/End Cover	Reinforced Polypropylene
Support Layer	Polypropylene
Pore Size(μm)	0.04;0.1;0.2;0.45;0.65;0.85;1.20
Seal Method	Thermal bonded,No Adhesives
O-rings/gaskets	Silicone;EPDM;Viton;Teflon;Nitrile;etc

Dimensions

Outer Dimension	69mm(2.75”)
Inner Dimension	33mm(1.30”)
Length	254mm(10”);508mm(20”);762mm(30”);1016mm(40”)
Filtration Area	0.65㎡per 10”

Performance

PH Value	6-14
Normal Operating Temperature（℃）	up to 65
Maximum Operating Temperature（℃）	80
Normal Flow Direction	4.2bar(60psi)@25℃
Reverse Flow Direction	2.1bar(30psi)@25℃
Sterilization	30 minutes at 135℃ Cumulative time:3 hours Autoclave 30mins(optional)

Safety

Endotoxin	<0.25EU/ml
Extractables	0.03g/10”

Quality

• The filter elements are produced in a 100.000-grade clean environment.
• Strictly implement the THEISO9001:2015 quality management system.
• All filter core materials and components are made of FDA-certified materials.

Order Information

HPES-L01010KKS H=chemical PES=PES(Polyethersulfone) 010=Pore size 0.10μm 10=10″ KK=DOE S=Silicone
Code	Grade	Code	Media	Code	Pore Size(um)	Code	Length(in)	Code	Connection	Code	O-ring/Gasket
H	Chemical	PES	PES	010	0.20	10	10″	KK	DOE	S	Silicone
E	Electronic			020	0.45	20	20″	LN	222/Fin	V	Viton
P	Phamaer			065	0.65	30	30″	MN	226/Fin	E	Epdm
F	Food			100	1.00	40	40″	LF	222/Flat	N	Nitrile
								PF	215/Flat	T	Teflon

Our Service

After-sales Service Team.

OEM Service: Customized Logo, Customized Package.

Delivery time:3-5 working days.

Shipping: Express(FedEx;UPS;TNT;DHL,etc) / Sea shipping/Air shipping/By train.

Packing: Free pallet package (OEM Packing is also available).
